JBL PRX710 aktivna zvučna kutija

Description

The PRX700 Series represent an evolutionary step in the efficient use of amplifier power, rugged durability and enhanced versatility in a self-powered loudspeaker designed from the ground up to perform in the real world of sound reinforcement where challenging audio environments, high ambient noise levels and loud volumes are typical. They are the first systems to use our patented Differential Drive technology with ferrite drivers featuring high power, wide bandwidth and low distortion. Versatile, scalable, easy-to-transport and set up, the PRX700 Series use JBL’s tour tested technology throughout for a lifetime of reliable performance you can trust.

SPECIFICATIONS
– Power Rating: 1500 W
– AC Power Input: 100V – 240V~ 50/60 Hz
– Frequency Range (-10 dB): Normal: 50 Hz – 19.6kHz Boost: 42.9 Hz – 20kHz
– Frequency Response (±3 dB): Normal: 63.5 Hz – 18.5kHz Boost: 53 Hz – 18.6kHz
– Coverage Pattern 100° x 60° nominal
– Directivity Index (DI): 9 dB
– Directivity Factor (Q): 8
– Crossover Frequency: 1.9 kHz
– Maximum SPL: 133 dB
– Dynamic Control (Input): dbx Type IV™ limiter circuit
– Input Impedance: 20K Ohms (balanced), 10K Ohms (unbalanced)
– LF Driver: 1 x JBL M110-4 250mm (10 in) woofer
– HF Driver: 1 x JBL 2408H-2 37.5 mm (1.5″) annular polymer diaphragm, neodymium compression driver
– Enclosure: Trapezoidal, 18 mm, plywood
– Suspension / Mounting: single 36 mm pole socket, 8 x M10 Suspension Points, 1 x M10 pull back point
– Transport: 1 x integrated handle with injection molded backing cup
– Finish: Obsidian DuraFlex™ finish
– Grille: Powder coated, Obsidian, 16 gauge perforated steel with acoustical transparent black cloth backing.
– Input Connectors: 2 x Balanced XLR / 1/4 inch input, 2 x unbalanced RCA input
– Output Connectors: 1 male XLR balanced output
– Dimensions (H x W x D) 498.7 mm x 335.6 mm x 322.3 mm
– Net Weight 16.4 kg
